High pressure ball press machine( two roller)
High pressure ball press machine( two roller)
If you want to know more information about our machine , please sent email to zhengzhouyuxi@yuximachine.com, we will give you the most professional reply at first time !
Major role and characteristics:
The machine can press all kinds of mineral powder, metal powder, coal powder, coke powder and other materials to make them molded. Because of the mandatory squeeze roller,so the products have the three high characteristics: high density ,high strength ,high hardness, Becauseof the mandatory
squeeze rollers, so the products have high density, high strength, high hardness, and the local roll is used in 650Mn hard materials with good wear resistance. Effectively improve the life of a roll
raw material :
The raw material comes from small size waste charcoal broken in storage or while transportation, or comes from charcoal chunk after biomass burned. With this machine, the waste charcoal chunk can be made into charcoal briquettes or charcoal stick and recycled for barbecue, room heating etc.
type of ball press:
two roller
This type of briquette press have two larger rollers in a fixed position in the frame, the other two smaller rollers are moveable. As its named implied, it has four rollers and press briquettes for twice times, so it make briquettes stronger and in higher density. This machine is national patent product in China.
The output briquette is in high quality and strong (not easy broken) that won't be broken when dropped from 150-250cm height. Meanwhile, it is easy for combustion, no smell and last longer when burning.
Model
|
290
|
360
|
430
|
500
|
650
|
800
|
1000
|
Roller Dia ( mm)
|
290
|
360
|
430
|
500
|
650
|
800
|
1000
|
Motor Power(KW
|
5.5
|
7.5
|
15
|
18
|
25
|
30
|
45
|
Capacity (t/h)
|
1-3
|
4-6
|
6-8
|
8-10
|
10-15
|
15-20
|
22-30
|
by a split gear, to ensure the synchronization of two rollers (constant reverse) material storage silo
hopper evenly into the molding equipment by quantitative so that the material forming
3.Features of the high pressure ball press machine
3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
