Tire Grinder
Tire Grinder
If you want to know more information about our machine , please sent email to zhengzhouyuxi@yuximachine.com, we will give you the most professional reply at first time !
If you want to know more information about our machine , please sent email to zhengzhouyuxi@yuximachine.com, we will give you the most professional reply at first time !
.jpg) |
Tire Shredder is used to shred radial tire and fiber tire into tire chips of 50×50mm size in ambient process, the tire needs to be debeaded before shredding. It mainly consists of motor, speed reducer, machine frame, shredding blades, rotary screener, transmission system, etc.
Structure and Principle
The shredding chamber adopts folio compact structure for easy maintenance.
The shredding blade edges are made of hard alloy after special hardness treatment, wear-proof. The blade edges are made hardness treatment, wear-proof. The blade edges are made replaceable without dismantling the machine, blade changing and repairing jobs are made easy and not costly and more. Heavy-duty, advanced technology and high output.
The machine adopts low noise, steady and high torque planet gear speed reducer, easy and safe operation.
The rotary screener is of steel net structure which has large area for screening qualified size of tire chips to discharge quickly. Low consumption, high output and advanced technology.
Technical Data
|
Model
|
900
|
1300
|
|
Capacity(T/H)
|
0.8-3
|
2-5
|
|
Feeding size(mm)
|
≤Φ850
|
≤Φ1250
|
|
Output size(mm)
|
≤50*50
|
≤60*60
|
|
Motor power(Kw)
|
45+4
|
155+7.5
|
|
Main shaft speed(RPM)
|
16
|
13
|
|
Weight(T)
|
7.6
|
21
|
Packaging and shapping of our machines:
1. All the machines will be wrapped up with plastic film first (including the motor).
2. The plastic film bag wrapped machine, according to the size and weight to make wooden or iron box, put machine in and fixed the box after loading. (The box material can be made as your requirements)
3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
Our service for our customers:
♥. Pre-sale service: design and manufacture machines for you as your special requirements, provide you with project, process design, and purchase programm.
♥. On-sale service: accompany with you to look around our factory, explain the manufacture process of our machines, and check the working performance of our machines.
♥. After-sale service: engineers are available to install and debugging equipments of the whole production line, besides, commissioning and training operators on site.
